Oh sh....

A callgraph for C programs

I was playing with Egypt the other day. It's a very cool application. It'll generate a callgraph for your C programs, no more no less. Actually, doxygen (kind of) does that, but what I really liked about this application is its simplicity. From Egypt's page

Egypt neither analyzes source code nor lays out graphs. Instead, it leaves the source code analysis to GCC and the graph layout to Graphviz, both of which are better at their respective jobs than egypt itself could ever hope to be. Egypt is simply a very small Perl script that glues these existing tools together.

Code reuse at its best. Give it a try.

Brillant corporate inteligence

In the I bet somebody got a really nice bonus category, I found this one while trying to compile MySQL++ on Solaris: http://lists.mysql.com/plusplus/7811.

Don't worry though. Now it'll be renamed to #define ORACLE.

PS: Kind of related is the story about Oracle breaking everything after a %s/Sun/Oracle in the JVM [1], though in that case I'm more inclined to blame sloppy programmers.

[1] http://it.slashdot.org/story/10/07/28/2121259/Oracles-Java-Company-Change-Breaks-Eclipse

Easier inbox count with Gmail Favicon script

There's a very cool script to add to your browser but first:

• Do you try to keep your inbox count in 0 (but usually fail miserably)?
• Do you like (need!) to be notified when a new mail arrives?
• Do you like Opera?

If you meet this conditions then you are very sick and need professional help. In the meantime, go and check Gmail Favicon Alerts 3, a cool script which changes gmails favicon to show your current email count. It works on Opera but it makes it crash. Most likely the script is not the one to blame here...

Template Metaprogramming XVI: Appendix

I forgot but one thing about these posts: the titles. No one got the hint but they are all chapter names from one of my favorites series, Nowhere Man.

mv, mf, Ubuntu's "did you mean?"

Some time ago I found about Ubuntu's "did you mean" thingy on console. It's very cool. Of course, I found it after makeing a typo on the console, I wrote mf instead of mv. Ubuntu suggested I was trying to use "mv", but I could install "mf", if I wanted to. I was a little bored, so I researched a little bit what mf is.

Turns out mf is metafont, a programming language to define vector based fonts (!), kind of like postscript. It's written by Donald Knuth, and there are three bits of trivia which make this post somewhat meaningful:

• The program's version number asymptoticaly aproaches e, right now it's on version 2.718281
• rtfm! The section on comments says: Warning: Type design can be hazardous to your other interests. Once you get hooked, you will develop intense feelings about letterforms; the medium will intrude on the messages that you read. And you will perpetually be thinking of improvements to the fonts that you see everywhere, especially those of your own design.''
• And lastly, on the bugs section: On January 4, 1986 the ``final'' bug in Metafont was discovered and removed. If an error still lurks in the code, Donald E. Knuth promises to pay a finder's fee which doubles every year to the first person who finds it. Happy hunting.

To log or not to log

Logging is nice, we all know that. It saves you from having to stay up all night checking when and why your applications fails. It servers to blame the support guys for not reading it. It's useful to stress test your RAID.

But logging where you shouldn't is a pain in the ass waiting to happen.

When designing an application you should choose between domain level objects, wiring objects, library level objects, helper objects, etc. Your logging should be mostly in the wiring of your applications, not in the helper objects and very rarely in the domain level objects. These objects, when well designed, are supposed to be tested and to be run in a production environment with many different loggers. If you log in the middle of your business object you may end up writing logs through cout when you're testing, or worse, when you're supposed to be logging in syslog.

Know where your objects live

If you work in an environment where memory management is part of your responsibility then you should be aware of the corner cases in which memory management may come and bite you in the ass. Object ownership is one of those areas.

If you are going to take ownership of an object you need to be very explicit about it. A common (and mostly wrong) pattern is taking ownership of an object, by default. Things work great until you end up with a production coredump after trying to free an invalid pointer.

Foo f1;
Foo *f2 = new Foo;

class BadList {
  Foo *f1, *f2;
  BadList(Foo *f1, Foo *f2) :f1(f1), f2(f2) {}
  ~BadList(){ delete f1; delete f2; }
}

Seen like that it's more than obvious, but I have seen even experieced programmers fall in this caveat. Related reading: Oh shit the stack.

Stacktrace or GTFO

Remember:



Also, because otherwise this post would be empty:

Template Metaprogramming XV: Gemini

This is the end. My only reader, the end. After 15 chapters of template metaprogramming you should have learned why staying away from them is a good idea, but if you have been following this series then you should know now when and why they could be useful.

These posts were a compendium of mostly isolated data I found during my travels through the depths of metaprogramming tricks, there are books and people much more capable than me if you want to learn more about this subject (Modern C++ Design by Andrei Alexandrescu comes to mind).

The whole idea of having a cache and a virtual template method was nice, but after seeing the result I decided it was best to have a factory method and an IDL. It may not be so l33t, but whoever has to maintain the code after me will be grateful.

This is the last post on this topic because I feel I have written most, if not everything, I can transmit through this medium but also for an important reason, most likely I won't be working with C++ code so much from now on [1] so there won't be as many chances for me to see the dark, insane, side of this beautiful (in its own way) programming language in a programming language. I know most of you must have barely skimmed through these articles, but I still hope you enjoyed them.

[1] That's right, I'm leaving C++ for the dark side of development, I'll be working with Java from now on. Keep in mind this article may have been written a long time before it's published.

[2] Wow, it was a long time since I used the meta-post category

Redshift: Cool your monitor

I've been trying Redshift the last few days. It's a really cool (pun intended) and simple program. It just sits there all day long, doing nothing. Yeap, it's just one more pointless thing on your ps -ef list, up until noon, when it comes to life: it will adjust your monitor's temperature, gradually, from a cool color to a warmer color.

Say what?

I know what you are thinking. "Why the hell did I eat so much cake?". And probably something like "WTF? Monitor temperature? Mine is running cool, k thx bye" too. The monitor temperature (color temperature, to be more accurate) is the percieved temperature of an object emiting light at the specific wavelength of that color:

So, a blueish color means a higher temperature, and it's the natural ambience light color you see during the day. Towards the night the color temperature begins too cool down towards a more orange color. This is the temperature Redshift changes.

So what?

Fair question. After a couple million years our brains got used to seeing a hot color temperature during the day (do I have any reader that old?) so staring at a blue monitor all day will keep you awake all night long, the theory being that switching its temperature towards a reder color will help you sleep at night.

Does it work?

Probably not, but that doesn't make it any less cool (pun not intended). I think if you fine-tune this app to your sleeping hours it may be of some use, because otherwise you'll get a very dark screen at 5pm (don't you people know the timezone in Argentina is FOOBAR'd).

Quote of the week

It seems making a compile fail is actually quite easy. That’s what I have most experience with.

From "Template metaprogramming", chapter 10 by me

Template Metaprogramming XIV: Marathon

If you remember previous entry, we got our evil device to the point of getting a specific instance using only a type hint. Now we need to put all the code together. I won't add much to the code, you should be able to parse it yourself.

/***********************************************/
struct NIL {
    typedef NIL head;
    typedef NIL tail;
};

template <class H, class T=NIL> struct LST {
    typedef H head;
    typedef T tail;
};
/***********************************************/

/***********************************************/
template <class X, class Y> struct Eq { static const bool result = false; };
template <class X> struct Eq<X, X> { static const bool result = true; };
/***********************************************/

/***********************************************/
template <class Elm, class LST> struct Position {
private:
    typedef typename LST::head H;
    typedef typename LST::tail T;
    static const bool found = Eq<H, Elm>::result;
public:
    static const int result = found? 1 : 1 + Position<Elm, T>::result;
};

template <class Elm> struct Position<Elm, NIL> {
    static const int result = 0;
};
/***********************************************/


/***********************************************/
template <typename LST, int N> struct Nth {
	typedef typename LST::Tail Tail;
	typedef typename Nth<Tail, N-1>::result result;
};

template <typename LST> struct Nth<LST, 0> {
	typedef typename LST::head result;
};
/***********************************************/


/***********************************************/
template <typename Lst> struct Instances {
    typedef typename Lst::head Elm;
    Elm instance;
    Instances<typename Lst::tail> next;
};
template <> struct Instances<NIL> {};
/***********************************************/


/***********************************************/
template <int N, typename TypeLst> struct NthInstance {
    // This one isnt easy...

    // This is the next type in the list
    typedef typename TypeLst::tail TypeNext;

    //  * Nth::result is the Nth type in Lst (i.e. char, int, ...)
    typedef typename NthInstance<N-1, TypeNext>::NthInstanceType NthInstanceType;

    //  * typename Nth::result & is a reference to said type and the ret type
    template <typename InstancesLst>
    static NthInstanceType& get(InstancesLst &instances_lst) {
        return NthInstance<N-1, TypeNext>::get(instances_lst.next);
    }
};

// Remember, just for fun we choose a 1-based system (wtf..)
template <typename TypeLst> struct NthInstance<1, TypeLst> {
    typedef typename TypeLst::head NthInstanceType;

    template <typename InstancesLst>
    static NthInstanceType& get(InstancesLst &instances_lst) {
        return instances_lst.instance;
    }
};
/***********************************************/


class Facade {
    typedef LST<int, LST<char, LST<double> > > Lst;
    Instances<Lst> instances;

    public:
    template <typename PK> int find(PK) {
        return Position<PK, Lst>::result;
    }

    template <typename PK>
    // This is a difficult one... it should be parsed like this:
    //  1) Get the desired instance position using Position::result
    //  2) Get the type @ the desired position with NthInstance::Type
    //  3) Define said type as a return type (with an & at the end, i.e. make
    //      it a reference to the return type)
    typename NthInstance< Position<PK, Lst>::result, Lst >::NthInstanceType&
    get_instance(PK) {
        const int idx_position = Position<PK, Lst>::result;
        typedef typename NthInstance<idx_position, Lst>::NthInstanceType IdxType;
        IdxType &idx = NthInstance<idx_position, Lst>::get( instances );
        return idx;
    }
};

#include <iostream>
int main() {
    Facade f;
    int &a = f.get_instance(1);
    char &b = f.get_instance('a');
    double &c = f.get_instance(1.0);
    a = 42; b = 'n'; c = 4.2;
    std::cout << f.get_instance(1) << "\n";
    std::cout << f.get_instance('a') << "\n";
    std::cout << f.get_instance(1.0) << "\n";
    a = 43; b = 'm'; c = 5.2;
    std::cout << f.get_instance(1) << "\n";
    std::cout << f.get_instance('a') << "\n";
    std::cout << f.get_instance(1.0) << "\n";
    return 0;
}

The only thing missing now is a map, to convert a primitive type to an index type, but that's trivial and so it will be left as an exercise for the reader (?). We just implemented the most evil code in the whole world. Next time, the conclusions.

Sorting by random in bash and mocp random updated

Random is nice. And now you can sort by random your output using sort -R. Why would this be useful? Well, I updated my mocp random script with a oneliner:

mocp -c && find -type d | sort -R | head -n1 | awk '{print """$0"""}'; | xargs mocp -a

C++ linking WTF

It is a commonly accepted fact that a succesfuly compiled application serves as enough proof of its correctness, but common wisdom doesn't say a thing about linking. If you like linker WTF moments, you'll love this snippet. Can you guess why won't it compile?

struct Foo {
    static const int x = 0;
    static const int y = 1;

    int z(bool x){
        return (x)? Foo::x : Foo::y;
    }
};

int main() {
    Foo z;
    std::cout << z.z(true);
    return 0;
}

Well, it does compile (gotcha!) but it just won't link. Yet it seems so simple... let's add some more mistery to this WTF moment, try this change:

    int z(bool x){
        int t = Foo::x;
        return (x)? t : Foo::y;
    }

Holy shit, now it compiles? WTF? Some more strangeness:

    int z(bool){
        return (true)? Foo::x : Foo::y;
    }

And again, now it compiles. WTF? I'll make a final change, this one should give you a clue about why it won't compile. Revert all changes back to the original code but add this two lines after Foo:

const int Foo::x;
const int Foo::y;

Though weird at first, now you should have a clear picture:

• The first case doesn't compiles: x and y are declared in struct Foo, yet the linker doesn't know in which translation unit they should be allocated.
• The second and third cases... well I'm not sure why does this compiles but it's probably because the linker can asume in which translation unit x and y should be allocated. I'm to lazy to check.
• In the last case we explicitly say where should x and y be. According to standard, this is how these two ints should be declared.

So, some linker strangeness. Beware, it's easy to get trapped by this one.

Vim Sexual Care

Vim bestows its users all sort of magical properties, among which now we can count increased sexual performance. I bet you didn't know, but Vim can help you keep your girl happy for days without end. Don't believe me? Check this page.

Template Metaprogramming XIII: Heart of Darkness

Last time we had a virtual template dispatch problem... we got to the point of knowing which was the index of the cache we were searching for, now we need to actually retrieve an instance of that cache. That's a problem. Why? To begin with, there are no instances, only types!

The next logical step would be to create a Map device, to map a list of types to a list of instances... let's see how can we do that, in pseudocode

instances( H|T ) <- [ create_instance(H), instances(T) ]
instances( NIL ) <- NIL

Looks easy. How can we map that to c++?

template <class Lst> struct Instance {
    typedef typename Lst::head Elm;
    Elm instance;
    Instance< typename Lst::tail > next;
};
template <> struct Instance<NIL> {};

#include <iostream>
using std::cout;

int main() {
    typedef LST<int, LST<char, LST<float> > > Lst;
    Instance<Lst> lst;
    lst.instance = 1;
    lst.next.instance = 'a';
    lst.next.next.instance = 3.1;
    std::cout << lst.next.instance << "n";
    return 0;
}

All those next.next.next.instance look ugly. Let's use some more meta-magic to get the Nth instance (why not a [] operator? several reasons, you can't mix non-const ints with templates nicely, there would be problems to define the return type... all those options are workable but it's easier if we do this in another device.

template <typename LST> struct Nth {
	typedef typename LST::tail Tail;
	typedef typename Nth::result result;
};
template <typename LST> struct Nth {
	typedef typename LST::head result;
};

Remember that one from the toolbox? Now we know how to get a specific index position, yet getting the instance is a different problem (the Nth device returns a type, not an instance). We should do something different, the problem is knowing the return type. What's the return type for the Nth instance of the Instances list?

   type <- Nth(TypesLst, Type)
   type var <- NthInstance(InstancesLst, N)

Not so easy, right? This is the translated C++:

template <int N, typename TypeLst> struct NthInstance {
    // This one isnt easy...

    // This is the next type in the list
    typedef typename TypeLst::tail TypeNext;

    //  * Nth::result is the Nth type in Lst (i.e. char, int, ...)
    typedef typename NthInstance<N-1, TypeLst>::NthInstanceType NthInstanceType;

    //  * typename Nth::result & is a reference to said type and the ret type
    template <InstancesLst>
    static NthInstanceType& get(InstancesLst &instances_lst) {
        return NthInstance::get(instances_lst.next);
    }
};

// Remember, just for fun we choose a 1-based system (wtf..)
template <typename TypeLst> struct NthInstance<1, TypeLst> {
    typedef typename TypeLst::head NthInstanceType;

    template <InstancesLst>
    static NthInstanceType& get(InstancesLst &instances_lst) {
        return instances_lst.instance;
    }
};

And the code from fetching the instance itself is even more difficult, so I'll leave that for next time.

Date time WTF

Another one to add to my growing list of bad things about Ubuntu. For some reason my clock froze. I only noticed it when it started to be dark outside, for me the time had frozen at about 17pm.

Template Metaprogramming XII: You Really Got a Hold on Me

Remember our virtual template method problem, from the other time? (I know, I said the answer was scheduled for a week after that post, but then I just forgot about it). May be we could avoid the virtual part by keeping a list of all our caches... how would we know which one should we dispatch the message to? Easy, using templates.

Instead of a list let's keep two, for twice the fun. One for the rows cache, another for the PKs. We can use PK to know which ROW Cache should we choose. Let's try to write a pseudo code for it:

ROW get_row(PK id) {
    pos <- Position of PK in pks_lst
    return cache[ pos ].get_row( id )
}

Doesn't look too hard. Building on our previous toolbox, let's use Eq, Position and the definition of a list:

struct NIL {
    typedef NIL head;
    typedef NIL tail;
};

template < class H, class T=NIL> struct LST {
    typedef H head;
    typedef T tail;
};

template <class X, class Y> struct Eq { static const bool result = false; };
template <class X> struct Eq<X, X> { static const bool result = true; };

template <class Elm, class LST> struct Position {
    private:
    typedef typename LST::head H;
    typedef typename LST::tail T;
    static const bool found = Eq<H, Elm>::result;
    public:
    static const int result = found? 1 : 1 + Position<Elm, T>::result;
};

template <class Elm> struct Position<Elm, NIL> {
    static const int result = 0;
};

class Facade {
    typedef LST<int, LST<char, LST<float> > > Lst;

    public:
    template <class PK> int find(PK) {
        return Position< PK, Lst >::result;
    }
};

#include <iostream>
using std::cout;

int main() {
    Facade f;
    std::cout << f.find(1.0) << "\n";
    return 0;
}

Great, now we can find an element on a list of types. The real virtual dispatch for the next entry :D

MySQL upsert, Oracle merge

How many times have you seen this "pattern"?

unsigned int row_count = foo->update();
if (row_count == 0) {
   foo->insert();
}

Wouldn't it be nice if you could write all that in a single line? Say, something like

foo->update_or_insert_if_it_doesnt_exists();

Well, good news, you can! Obviously it's not standard SQL, nothing useful ever is, but even so I think using an upsert (who comes up with those names?) can be quite good for your health.

So, how do you use it? It's easy;

INSERT INTO Table ( col1, col2 )
SELECT 'a', 'b'
ON DUPLICATE KEY UPDATE col1 = 'a', col2 = 'b';

Go on, try it, I'll wait. What? It didn't work? Oh, I forgot, you need to create a unique key so the engine can recognize when there is a duplicate key (say, 'create index unique on col1'). Try it now.

Nice, isn't it? Oracle has its own version of upsert, called merge (at least the name is better) but it itches a little bit when I write about Oracle, so go and check this page instead.

C++ Namespaces and g++

Have you ever tried to leave open a C++ namespace after EOF (that is, openning a namespace in a headerfile but forgetting to close it). It's a little bit like getting your balls caught by the door. The compiler will throw at you an incredible number of seemingly unrelated errors, all of which occur in a different file than the offending header.

Reaching EOF on a C++ file without closing all its namespaces should be ilegal; or at least you should have better error reporting, because right now it's almost impossible to know what's the source of the error (for g++, that is).

Oh my god

An old good Unix console joke goes like this:

% ar m God
ar: God does not exist

Obviously thats a very old and used joke, nowdays we're much more advanced than that:

$ ar m God
$ ar: creating God

Design Patterns: C++ Idiom RAII

Ohh design patterns. I love buzzwords. Who doesn't? To increase my buzzword count I will be writing about a topic most people programming C++ should already know: RAII, resource acquisition is initialization.

Patterns everywhere

Knowing that Gamma et al didn't list all the known patterns in the universe does come as a surprise to some, not sure why though. The twenty some patterns they write about in their now famous book are (arguably, perhaps) some of the most common design patterns, but the list hardly finishes there.

Some patterns only have meaning in a very specific context; a reactor is a nice pattern for handling asynchronous events yet most applications would never need it. Sometimes "the context" means a specific domain in which the application must work, like a web application, a real time application or a distributed application, sometimes the context is the language itself. RAII falls in this last domain, it only makes sense for C++ applications (actually there are others, but thinking what kind of languages would support this idiom is left as an exercise for the reader).

No, really. What is RAII?

If you made it past that long intro you are probably really interested in knowing what RAII is, and don't know how to search it in Wikipedia. OK, I'll explain it the best I can then: RAII means that a resource acquisition is the initialization.

Seriously. That is all the secret there is to RAII. Talking in code:

template
class RAII_Wrapper {
   T *resource;

   public:
      RAII_Wrapper (T *resource)
            : resource(resource)
      {
         resource->open();
      }

      ~RAII_Wrapper ()
      {
         resource->close();
      }
};

An example

Compare that to a visitor pattern. It's just too simple to be of any use, isn't it? Well, contrary to what Java fanboys tend to believe you can do lots of nice things without writing a bazillion lines of code.

int foo() {
	Expensive_Resource x;
	x.open();

	try {
		if (not bar()) {
			x.close();
			return -1;
		}
	} catch (...) {
		x.close();
		throw "up";
	}

	int ret;
	try {
		ret = baz();
	}catch(...) {
		// We don't care, we're closing x anyway
	}

	x.close();
	return ret;
}

Wow... a whole lot of code just for calling bar and baz. And as I wrote that without even compiling I'm sure there are too many hidden bugs, lots of code-paths my simple programmer's mind can't even begin to imagine which will cause my Expensive_Resource to be leaked!

Let's rewrite that using RAII:

void foo() {
	Expensive_Resource x;
	RAII_Wrapper release(&x);

	if (not bar()) return -1;
	return baz();
}

A lot nicer, isn't it? But, what happened to all the try/catch if's and closes there?

Where's the magic?

The magic of RAII lies in how C++ handles exceptions. When we have a built object (can an object be in an unbuilt state?) it means it's constructor has correctly ran. It also means it's destructor will run when it goes out of scope, doesn't mater HOW it goes out of scope.

See how brilant that is? Doesn't matter if a function we're calling throws, or if we need to return before reaching the end of the function: the destructor will be called and thus our Expensive_Resource will be free!

Why is this C++ specific?

This is an easy one: think how would you implement this in Java: right, you can't. Not knowing when is your object going to be destroyed means you can't do anything useful in its destructor, therefore RAII is deeply rooted within the memory management in C++ and it's pretty much a language specific pattern (or is it?). But, is that so good?

Not everything is so great...

You are probably thinking this is the best discovery since ice cream was invented. Well, not so fast, RAII has it's detractors too.

The first problem in RAII, it doesn't have a graceful way of handling resource acquisition failure. If Expensive_Resource is a database, and it's connection fails, we have a throwing constructor.

Even if throwing constructors are acceptable, throwing destructors may even be a worst idea: throwing while an exception is already active is a cause for concern (tip: it'll crash your application, doesn't matter how many try/catch blocks you use, due to stack unwinding issues).

And then, even if we don't care about throwing destructors you have the issue of a release failure: how do you notify the user that a release failure has occurred? And what do you do, should it happen?

So, RAII is a great idea indeed, and it has it's uses, but you should be careful when choosing this C++ specific pattern.

Fuuuuuuuuuuuuuu (Opera)

I hate ubuntu, but I hate windows the most. I hate firefox, but internet explorer makes me want to vomit. I don't like gnome, but kde is uglier. But I love Opera. Well, loved it, I guess version 10.60 will be my last version.

It's been a loyal application which I've been using since its 6.x version. Always fast, with all the functionality I needed (some more too) and none of the bloated BS needed to make FF be a usable (though ugly) browser. It had it's ussual screw-ups, everyone does, but after I updated to version 10.60 it has become unusable.

Its new features include random crashe, making gmail work really slow (or not at all: the fucking scrollbar won't work anymore, and keyboard shortcuts in google reader (j & k, next & prev) are foobar'd. Scrolling on a large webpage eats 100% cpu, the upgrade fucked up my nice dark theme (and changed it back to a hellish abomination which seems to be a time-traveller from 1998), and it has random stupid bugs. And I mean STUPID, like, double click a word and the popup menu won't go away.

Fuck. I always liked you Opera, but it seems it may be time to give chrome a chance.

Template metaprogramming XI: Hidden Agenda

Wow, number eleven already. We're getting more chapters here than Final Fantasy games. I didn't even imagine there was so much to write about such an esoteric language features like templates. I do wonder if anyone will actually read it, but that's a completely different problem.

Enough meta-meta talk: what can we do with all the things we have learned? We can calculate pi and e, we already showed that as an example on one of the first chapters. This chapter I'm going to write about what motivated me to explore the bizarre underworld of template metaprogramming. Some time ago I had to work with a Berkeley DB researching the feasibility of developing a magic cache for (real) DB table. Leaving aside the discussion of whether this is a good idea (the project did have a good reason to be researched) I hit a major roadblock when trying to provide a façade for every table; something like this:

See the problem? To do something like that we'd need a virtual template method, and you can't have that. After seeing that I thought to myself "Hey, I'll use templates!". Then I had two problems, but the damage was done, I couldn't go back. What kind of contorted device could we implement to make such a devious requirement work? I'll leave you to think it, the answers I came up with next week.

Thanks for flying vim

Have you ever used Vim through ssh and saw your xterm title changes to "Thanks for flying vim"? It happens a lot to me, and I usualy notice about an hour later. I'm not sure what's the use of this, I guess it's related to Vim airlines (no, really, check vim-avia.com), but it can be turned off:

When using vim in an xterm it renames the title of that window to "Thanks for flying vim" on exit. Q: How to turn off the message "Thanks for flying vim"? A: :set notitle

-- http://www.vmunix.com/vim/answ.html

The truth about SNMP

Seen @ http://wiki.wireshark.org/SNMP:

After years thinking and reading RFCs and various other documents, today, I finally understood. "Simple" refers to "Network" not to "Management Protocol"! So it is a Management Protocol for Simple Networks not a Simple Protocol for Management of Networks... That explains why it's called "Simple". It was that Simple but it took me years to understand it! -- LuisOntanon

Thank you Luis. That explains a lot.

Opera borks gmail

Ubuntu sucks, but less than windows. Gmail sucks, but less than hotmail. Opera rocks, but it tends to fuck up gmail every once in a while. After a lot of research and having found no help on the interweb I traced the problem to having a lot of tabs open for a lot of time (weeks, not hours).

In Firefox this shouldn't be a problem as having a FF browser open for a week should hog all the memory on its host computer, forcing you to reboot. In Opera, being a little bit better behaved browser, this may actually be a problem.

Luckly the fix is simple: open a Vim editor or take out pencil and paper, make a list of all your open tabs, close opera and using your favourite console type "rm -rf ~/.opera/sessions" (i.e. delete the sessions folder in your .opera dir). Restart Opera and restore your tabs from your backup list. Problem should be gone.

Elvis is alive!

Unix trivia day: in the olden days of the 90's there were a lot of Unix boxes out there named "elvis". Nowdays it's not uncommon to find one, either. Have you ever wondered why are there so many boxes called elvis?

This is related to Solaris' ping command. When you ping $HOST it prints "$HOST is alive" (if it's responding the pings), thus elvis is alive!

Vim tips: make things work again

Are you using :make within vim? If you are, then you probably noticed that getting lots of compiler errors is not uncommon, and that vim has a tendency of jumping to the first error found... but what happens if you want to see subsequent errors too, because you're a really crappy programmer and need to find the 10 or 20 errors you just introduced with your single line edit?

Luckily Vim is always the anwser, just use cnext and cprev until you reach the error you are looking for.

There's still hope

A log time ago, in a galaxy far away, I posted a list of stuff I apt-get'd as soon as my Buguntu install was ready. Well, fast forward to KK and this is the new apt-get script:

sudo apt-get install opera mocp unclutter build-essential gimp \
        mmv gnome-do knetworkmanager xdiskusage iptraf sshfs \
        shntool cuetools flac wavpack unrar vlc vim gvim vim-doc \
        vim-full vim-gnome ddd devhelp doxygen doxygen-gui \
        exuberant-ctags ctags  subversion ifstat antiword

Quite a progress I'd say, as these are mostly programs I use which don't come in the default install (even though they should). You know, I even have hopes for the sound system in my notebook this time...

Nooooooooooo

(gvim:13664): Gdk-CRITICAL **: gdk_window_get_user_data: assertion `GDK_IS_WINDOW (window)' failed
Vim: capté una señal de muerte SEGV
Vim: finalizado.

C++ pretty functions

There are two well known macros from the preprocessor which every macro-sorcer must know. They are __FILE__ and __LINE__. You probably already know about them but anyway, __FILE__ will give you the current file and __LINE__ the current line. Easy, huh?

int main() {
   printf("%s : %i", __FILE__, __LINE__);
   return 0;
}

The program above would give you "main.cpp : 3" as a result. There is nothing going on at execution time, it's all preprocesor wizardy. In fact with "g{++/cc} -E" you can even check what the "real" output is (-E means to return the preprocessor output. Keep in mind a lot of stuff will be included from the headers you use).

int main() {
   printf("%s : %i", "main.cpp", 3);
   return 0;
}

Well that's nice and all, but g++ can top this easily:

int main() {
   std::cout << __PRETTY_FUNCTION__ << "n";
   return 0;
}

There are a couple of notable things about this new "pretty function" thing:

• 1. It will demangle a function's name
• 2. This time it isn't a preprocessor secret thing but a real variable g++ will create.

You can easily use this for better logging functions now (with some macro wizardy, obviously).

Template metaprogramming X: Zero Minus Ten

So far we've learned the basic constructs of template metaprogramming (loops, branching, return values) and some basic list operations (getting the length of a list, appending and prepending elements, checking if an element is included in a list). Let's put it all together by creating an operation to return the position of an element. It'll be very useful later on too.

If we go back to the Includes operation we can get some help to define the Position operation: the position of an element in a list is one plus the position of the element we're searching for in the tail, or zero if the head equals said element. The operation is not defined if the element is not in the list.

Translating to pseudo-code:

Position (lst.head, lst) <- 0
Position (e, lst) <- 1 + Position(e, lst.tail)

The translation to C++ is not so trivial this time. Try it, I'll wait... ready? OK, let's start

template <class Elm, class Lst> struct Position {
	typedef typename Lst::head Head;
	typedef typename Lst::tail Tail;
	static const bool found = (Head == Elm);
	static const int result = found? 0 : 1 + next;
	static const int next = Position<Elm, Tail>::result;
};

Looks easy... but doesn't work. First problem, we can't compare two types, remember? We need to use Eq again. Second problem, although we said the operation is undefined if the element is not included on the list, it would be nice if we could force the compiler to fail if (or when) that happens. Let's rewrite the operation using a façade again, but adding an Assert:

template <typename Elm, typename LST> struct _Position {
	typedef typename LST::head Head;
	typedef typename LST::tail Tail;

	static const bool found = Eq<Elm, Head>::result;
	static const int result = (found)? 0 : 1 + _Position<Elm, Tail>::result;
};

template <typename Elm, typename LST> struct Position {
	typedef typename Assert<Includes< Elm, LST >::result>::check include;
	static const int result = _Position<Elm, LST>::result;
};

Oh, we haven't defined assert yet! There's another problem, too: even if it won't compile, the compiler will try to expand _Position< ..., NIL > indefinitely, causing an error after too many nested template calls. Not nice. We need to add a case to make the compiler stop:

/******************************************************/

// Helper: Will fail to compile if the assert is false
class Assertion{};
template <bool cond, class T=Assertion> struct Assert {
	typedef typename T::fail check;
};
template <> struct Assert<true> {
	typedef void check;
};

/******************************************************/

template <typename Elm, typename LST> struct _Position {
	typedef typename LST::head Head;
	typedef typename LST::tail Tail;

	static const bool found = Eq<Elm, Head>::result;
	static const int result = (found)? 0 : 1 + _Position<Elm, Tail>::result;
};

// The compiler will try to expand the position check
// after NIL has been reached if this isn't here
template <typename Elm> struct _Position<Elm, NIL> {
	static const int result = 0;
};

template <typename Elm, typename LST> struct Position {
	typedef typename Assert<Includes< Elm, LST >::result>::check include;
	static const int result = _Position<Elm, LST>::result;
};

All that code for such a simple operation, man. Also, see what we did with Assert<>? It seems making a compile fail is actually quite easy. That's what I have most experience with.

We've been through quite a lot, and our toolboox should be quite big already. Next time we'll start steering towards some sort of applicability, trying to use some of all these stuff to implement a real, useful and working program... assuming that's even possible.

Binary portability in Linux

An interesting topic for a change: is Linux binary portable? That is, can we take a binary file and be sure it'll run in any other Linux system? What happens if we broaden that to any POSIX system, will it blend? Eh, I mean, will it run?

Doing some research on the subject I wrote down a list of the thought process which led my to an (inconclusive) answer:

1. First we should define what a binary is for us: When we talk about a binary we are usually thinking about a compiled binary file, not an interpreted script file like Ruby or Python. Those are for people who like things to actually work, so let's focus on a compiled executable file, like a C/C++ application.
2. Defining compiled file: What could it be other than a sequence of bytes the microprocessor can understand? Yes, that's right, it's sort of interpreted code, only there's electronics behind, not more code. This brings us to the first interesting conclusion: the executable must be (leaving emulators aside) compatible with the architecture you're on. Running Sparc? Well then, the binary better be compiled for Sparc because otherwise to the uP will not make any sense.
3. Format: as any other thing, a binary file must have a format. That is a standard which defines the structure the file will follow. ELF is the binary format for Linux and it's quite standard. Of course, if the binary format is a standard then we should get perfect portability between different platforms running on equal architecture. Unfortunately that's not the case.
4. (Cont'd) Why don't we? The binary depends not only on compile time "stuff" but a loading time linking occurs: the executable binary will get linked with the system files like glibc, or any other dependency on a shared library it may have.

So, what are the keypoints for Linux binary portability? Architecture, binary format and system libraries.

Of course, making the executable run is only part of the equation, as running and segfaulting on the spot is not so nice either. For this last part you'll have to closely follow the standards defined by POSIX for paths and stuff like that.

Epilogue

As an epilogue, we could add that Windows binary compatibility tends to be great. Running binaries from 12 years back is no small feat, yet this leads to a whole lot of other problems: an incredible complex loader, security bugs, backwards compatibility headaches, et al. The old new thing is a great source of information for this topics, I'm quite illiterate about Windows binaries nowdays :)

Followup links

• http://evanjones.ca/portable-linux-binaries.html
• http://autopackage.org/docs/devguide/ch07.html (I swear this one was working when I wrote this text... a year ago)

Vim tips: make things work

So, you are an uber console geek, using only vim and the command line to compile all your projects, execute the tests, blah blah blah... if only you could squeeze that microsecond lost whenever you switch from vim to compile you'd be 1e-4 seconds more productive... oh, wait, you can!

Whenever you think you're project is good enough to compile just hit :make to be proven wrong. Type :make test to run your tests (because you are using TDD, aren't you?) and watch all those red flags fly by.Also, add the following mapping to your ~/.vimrc for an extra happy coding session:

map <F5> :make
map <F6> :make test

Template metaprogramming IX: Absolute Zero

By now we should have learned how to perform loops, branching and returns using templates. Let's add a couple of useful operations to our library: append and prepend.

Prepending an element to a list is very easy: the result is a list (oh surprise) consisting of a head (the element we want to add) and a tail (the old list). In the pseudocode I've been using so far:

Prepend(e, lst) <- LST(e, lst)

And in C++ (trivial, this time):

template <typename Elm, typename Lst=NIL> struct Prepend {
	typedef LST<Elm, Lst> result;
};

Appending is a little bit more difficult, as we need to first find the end of the list. Think for a second how would you define it... back? Ok, I'd define it this way: appending an element to the list yields a list, consisting of the same head and the result of appending said element to the tail. The null case, as usual, is appending an element to a NIL list; in this case the result is a list with the element itself. So:

Append(e, NIL) <- LST(e)
Append(e, lst) <- LST(lst.head, Append(e, lst.tail))

Looks complicated but it follows the same structure as the rest of the basic-ops:

template <class Elm, class Lst> struct Append {
	typedef typename Lst::head Head;
	typedef typename Lst::tail Tail;

	typedef typename Append<Elm, Tail>::result Next;
	typedef typename LST<Head, Next>::result result;
};

template <class Elm> struct Append<Elm, NIL> {
	typedef LST<Elm> result;
};

Easy. Now, what happens if we want to add a default value for Lst, so we can use Append to create lists? Easy too, but we need a façade this time; just rename Append to _Append, then

// This is here just because I wanted a default param :D
template <typename Elm, typename Lst=NIL> struct Append {
	typedef typename _Append<Elm, Lst>::result result;
};

I promised to add one more operation to our toolbox, returning the position of an element, but this post is getting quite long and I'm afraid it may be too much for the average attention span of a programmer... we'll leave it for next time.

Just WTF

Who the hell can create a monster like this one?

CREATE PROC shutdown10
AS
EXEC xp_cmdshell 'net send /domain:SQL_USERS ''SQL Server
shutting down in 10 minutes. No more connections
allowed.', no_output
EXEC xp_cmdshell 'net pause sqlserver'
WAITFOR DELAY '00:05:00'
EXEC xp_cmdshell 'net send /domain: SQL_USERS ''SQL Server
shutting down in 5 minutes.', no_output
WAITFOR DELAY '00:04:00'
EXEC xp_cmdshell 'net send /domain:SQL_USERS ''SQL Server
shutting down in 1 minute. Log off now.', no_output
WAITFOR DELAY '00:01:00'
EXEC xp_cmdshell 'net stop sqlserver', no_output

Template metaprogramming VIII: A Rough Whimper of Insanity

Remember last time? We learned how to get the lenght of a list. This time I'll introduce some more of these basic ops. Let's begin with "Nth": getting the Nth element of a list; which, remember, in this case is a type, not a concrete element. This means the Nth element will be something like int, char, const char*, not 1, 2 or 3. We introduced a trick to get around this limitation before using a template , go there to refresh your memory if needed.

So, what would the coloquial definition of "Nth" be? I'd put it like "The operation Nth for a list equals the head of the list for N = 0 and Nth (minus one) of the tail otherwise". A little bit more formally:

Nth(0, lst) <- lst.head
Nth(n, lst) <- Nth(n-1, lst.tail)

Translating this to C++ should be a breeze to you now. Try it, I'll wait. Read? OK, this is MY answer:

template <typename LST, int N> struct Nth {
	typedef typename LST::Tail Tail;
	typedef typename Nth<Tail, N-1>::result result;
};

template <typename LST> struct Nth<LST, 0> {
	typedef typename LST::head result;
};

Though the structure is very similar to the previous "basic operation", getting the length of a list, the concept is quite different. This time we're defining a return type recursively. Anyway, it was too easy indeed, let's try a more complex operation now.

How can we check if an element exists on a list? Seems easy enough, an element is included in a list if the head equals the element itself or if the element is included in the tail. In the pseudo language I just invented:

Includes(lst.head, lst) <- true
Includes(e, lst) <- Includes(e, lst.tail)

Looks easy, right? Well, there's a bug there, can you spot it? Yeah, we're missing the false condition. We should add a third specialization:

Includes(lst.head, lst) <- true
Includes(e, NIL) <- false
Includes(e, lst) <- Includes(e, lst.tail)

Again, let's translate the pseudocode to C++. Try it, I'll wait. Read? OK, this is MY answer:

template <class Elm, class Lst>
struct Includes {
	typedef typename LST::head Head;
	typedef typename LST::tail Tail;

	static const bool found = (Elm == Head);
	static const bool found_tail = Includes<Elm, Tail>::result;
	static const bool result = found || found_tail;
};

template <class Elm> struct Includes <Elm, NIL> {
	static const bool result = false;
};

Looks nice, doesn't it? Too bad it won't work, you can't compare two types. What would (int == char) mean in C++? We need a helper there, some kind of trick to compare two types. We can use partial template specialization again:

template <class X, class Y>
struct Eq { static const bool result = false; }

template <class X>
struct Eq<X, X> { static const bool result = true; }

With this little struct now we can write our include operation this way:

template <class Elm, class Lst>
struct Includes {
	static const bool result = Eq<Elm, typename LST::head>::result
				   || Includes<Elm, typename LST::tail>::result;
};

template <class Elm> struct Includes<Elm, NIL> {
	static const bool result = false;
};

Very esoteric looking, the right mix of Haskel, C++ and booze to ensure job security for life. Next time we'll find a way to search for the position of an element, a somewhat more complicated task.

Oh shit, the stack

Post from the wayback machine. I wrote this a long time ago but it got way down the posts queue, don't know why

I liked my vacations very much, thank you. Some people enjoyed vacations from me too. At work they even decided to keep this gem for my return. Upon my arrival a nice coredump was waiting at my desk, so to speak. Check it out, isn't it beautiful?

0 0xff05d070 in inflate_fast () from /usr/lib/libz.so
1 0xff05a13c in inflate () from /usr/lib/libz.so
2 0x00146224 in ZDecompress::decompress (this=0xfbc7b300, sauce=@0xfbe7b740, dest=@0x27c910) at Compressor.h:134
3 0x00145e80 in HandleClient::get_client_data (this=0x27c810, output_stream=0x27c910) at IPC/DataReceiver.cpp:54

Yeah, that's getting killed inside zlib. Nice way to start the year, a bug in zlib. What led me to that conclusion? Easy, the same compressed file worked in Ubuntu. Must be a bug in zlib then!

The next step was getting zlib's code and adding enough printf's to know the problem was in the middle of the file, not at the beginning nor the end; indeed, most of the file could be correctly decoded, but then it just died. This looked more and more like a bug in zlib.

I began to scramble things around, trying to isolate the problem. Things just got weirder, the same code worked fine if instead of being inside a thread I was on the main thread. If you have psychic powers you now have enough information to know what the problem was. Although I should have known too (this wasn't even the first time I saw a problem like this one!) I was mindset on finding a bug in zlib, which now, it seems, only appears while interacting with ACE (in my defence, I did see these kind of bugs too).

Fiddling around with the code some more, even stranger backtraces began to appear. First this one:

Program received signal SIGSEGV, Segmentation fault.
[Switching to LWP 10]
0xfd6b88fc in _pollsys () from /usr/lib/libc.so.1
(gdb) bt
#0  0xfd6b88fc in _pollsys () from /usr/lib/libc.so.1
#1  0x696e7661 in ?? ()
#2  0x696e7661 in ?? ()

And then this other one, which led me into the right direction:

Program received signal SIGSEGV, Segmentation fault.
[Switching to LWP 9]
0x000b6784 in std::operator| (__a=Cannot access memory at address 0xfbb7b094
)
    at /usr/local/lib/gcc/sparc-sun-solaris2.10/3.4.6/../../../../include/c++/3.4.6/bits/ios_base.h:124
124       { return _Ios_Openmode(static_cast(__a) | static_cast(__b)); }
(gdb) bt
#0  0x000b6784 in std::operator| (__a=Cannot access memory at address 0xfbb7b094
)
    at /usr/local/lib/gcc/sparc-sun-solaris2.10/3.4.6/../../../../include/c++/3.4.6/bits/ios_base.h:124
#1  0x00152d5c in HandleClient::get_client_data (this=Cannot access memory at address 0xfbb7b088
) at IPC/DataReceiver.cpp:46

That last stack trace got me to think how could it be possible for an otherwise working program to coredump while creating an stdlib object. I mean, stdlib is quite well tested, isn't it? Then it struck me: the keyword isn't stdlib but creating. It was allocating memory from the stack, upon entering the function.

Some more research later I found out that Solaris default thread size is about 1 mb, while in Ubuntu this thread is of about 8 mb. And I also noticed the buffer I was allocating for zlib was taking up space in... the stack.

If there's something to learn from this story is that you should always know what goes in the stack: only small objects should live there, and you should always know the max stack depth a function could reach. Otherwise it may come back and bite you in the ass when you're back from your vacations.

Template metaprogramming VII: The Enemy Within

Remember where were we last time? We had this code to define a list:

struct NIL {
	typedef NIL Head;
	typedef NIL Tail;
};

template <typename H, typename T=NIL> struct Lst {
	typedef H Head;
	typedef T Tail;
};

template <int N> struct Int{ static const int result = N; };
typedef Lst< Int<1>, Lst< Int<2>, Lst< Int<3> > > > OneTwoThree;

Now, to increase our template-foo, let's practice some basic operations. The same operations you would implement to practice your skill any other functional language. If I remember correctly these where useful when learning Haskel: getting a list's lenght, getting the Nth element, appending and preppending elements... that sort of stuff.

Let's start with the most basic: getting the length of a list. We don't really have a for loop so using recursion is the only way. It gets easier if we think again on our definition of list: "think of a list as tuple, two elements, the first (called head) will be the first element of the list and the second element as another list or a NIL object". Whit this definition of a list, then it's length turns to be 1 (the head) + the length of the remaining list (the tail), with a special case for the length of a NIL object which should always be 0. In template-speak:

template <typename LST> struct Length {
	typedef typename LST::Tail Tail;
	static const unsigned int tail_length = Length< Tail >::result;
	static const unsigned int result = 1 + tail_length;
};

template <> struct Length <NIL> {
	static const unsigned int result = 0;
};

I know. You are thinking "wait, what?". Well, even for this basic case we need to use some esoteric language features:

• typename is needed to tell the compiler LST::Tail is a type and not a static variable (like Length::result is). Did you remember that from chapter IV?
• We have to use recursive templates, but you probably already figured that out. You should remember this from chapter II.
• We can provide a spetialization of a template. You should also remember this from chapter II.

Obviously, you can write it this way too:

template <typename LST> struct Length {
	static const unsigned int result = 1 + Length< typename LST::Tail >::result;
};

template <> struct Length  {
	static const unsigned int result = 0;
};

The rest of the "basic" list-operations are quite similar, but I'll leave that for another post.

---

Thank you Stéphane Michaut for pointing out typos and bugs in the code listings

Deleting > Writing

Perfection is finally attained not when there is no longer anything to add but when there is no longer anything to take away, when a body has been stripped down to its nakedness.

Antoine de Saint-Exupery

Level up!

Today it’s been 756864000 seconds of uptime since I was promoted from Release Candidate to V1.0. Hope none of you remember I made this same post 31536000 seconds ago.

Template metaprogramming VI: The Spider Webb

We have been building our template meta-foo for five chapters now, and I think we are ready to move on to more advanced topics. We will be borrowing a lot more from functional languages from now on, so you may want to actually start practicing some template metaprogramming to keep advancing.

In our previous entries we worked with basic building blocks, making it quite easy to keep in mind the whole "program flow". Now it won't be so easy anymore, as we'll be using real metaprogramming (i.e. templates operating on templates) so a lot more thought will be needed for each program.

Another point to keep in mind, you don't have a debugger here. All the magic occurs at compile time so there is no gdb to step through your program to find a logic flaw. There's a little trick to check if you are too far off from the target but, mainly, you'll have to think for yourself.

Let's start with any functional programming course basics: lists. We have to think, first, how can a list make any sense when you only have types and no values. It means you can have a list like "int, char, void**, Foo", and not something like "1, 2, 3". Or, can you? There's a way to trick the compiler into creating a type from a integral value:

template <int N> struct Int {
	static const int value = N;
};

Voila! Now you can create a list of numbers. For our next trick, let's implement the list itself. No pointer magic, think of a functional definition of a list. Come on, I'll wait... ready? OK, a list is a tuple T of two values, in which the first element, called head, is the first element of the list and the second element, called tail, is either a list or the NULL element.

Quite a mouthful... let's go over that definition again:

// A list is a tuple T of two values
List: [ ..., ... ]

// in which the first element, called head, is the first element of the list
List: [ Head, ... ]

// and the second element, called tail,
List: [ Head, Tail]

// is either a list or the NULL element
List: [ Head, Tail]
Tail: List | Nil

So, as an example, a list of numbers could be expressed as:

	List( 1, List( 2, List( 3, NIL ) ) )

Closing up... how would you define this list in C++? Easy:

template <typename H, typename T> LST {
	typedef H Head;
	typedef T Tail;
};

We need here a NIL type to use as a list ending element. We could also use a default template type, so we won't have to write the last NIL to end a list definition. Thus we have now:

struct NIL {
	typedef NIL Head;
	typedef NIL Tail;
};

template <typename H, typename T> struct LST {
	typedef H Head;
	typedef T Tail;
};

Nice. You should remember the following rules:

1. We can use template to define a template class, defining a new type based on a number instead of another type ;)
2. We can't "store" a value in a type... unless we store it as a static value, that is.
3. Using a convention for defining result holding variable names is very useful, as there are no interfaces and more than once we'll be using a result from an unknown class

With that said, let's translate the list (1, 2, 3) to Tmpl C++

template <int N> Int{ static const int result = N; };
typedef Lst< Int<1>, Lst< Int<2>, Lst< Int<3> > > > OneTwoThree;

Not so bad to start with. Next time we'll be doing something a little bit more useful with this list.

One last note, initializing a static const int in the definition of the class may be non portable (some compilers seem to have trouble with it). An enum may be used instead.

Dealing with Office on Linux

Seen @ bash.org:

< adamkuj> are there any good open source tools for working with Access DB's (mdb files)? <@Dopey> rm Comment: #evilgeeks

True, so true... It's been said a thousand times, but I kinda like ranting... like it or not Office files are a majority out there. If you work with Linux, using it in a real enterprise environment, sooner or later you'll run into someone using a propietary Office format. You'll also run into someone who doesn't know that you need OOO to open those weird odf files. You may need to produce an adecuately formated document sometime, and LaTeX may not be an option.

Deal with it. Install a VM, or Wine, and a copy of MS Office. Resistance is futile.

Template metaprogramming V: Face to face

By now we have learned the basics for a nice template metaprogramming toolkit:

• Loops with recursive template definitions
• Conditionals with partial template specializations
• Returns using typedefs

Unfortunately that's all you need for a Turing complete language, meaning now we have the power, bwahahaha! Mph, I'm sorry, back on topic, it means we can now create a fully functional and useful template metaprogramming device... for approximating e, nonetheless. Oh, you think that's not useful? Well though luck, that's all you get for now:

template <int N, int D> struct Frak {
    static const long Num = N;
    static const long Den = D;
};

template <class X, int N> struct ScalarMultiplication {
    static const long Num = N * X::Num;
    static const long Den = N * X::Den;
    typedef Frak<Num, Den> result;
};

template < class X1, class Y1 > struct SameBase {
	typedef typename ScalarMultiplication< X1, Y1::Den >::result X;
	typedef typename ScalarMultiplication< Y1, X1::Den >::result Y;
};

template <int X, int Y> struct MCD {
	static const long result = MCD<Y, X % Y>::result;
};

template <int X> struct MCD<X, 0> {
	static const long result = X;
};

template <class F> struct Simpl {
	static const long mcd = MCD<F::Num, F::Den>::result;
	static const long new_num = F::Num / mcd;
	static const long new_den = F::Den / mcd;
	typedef Frak< new_num, new_den > result;
};

template < class F1, class F2 > struct Sum {
	typedef SameBase<F1, F2> B;
	static const long Num = B::X::Num + B::Y::Num;
	static const long Den = B::Y::Den; // == B::X::Den
	typedef typename Simpl< Frak<Num, Den> >::result result;
};

template <int N> struct Fact {
	static const long result = N * Fact<N-1>::result;
};
template <> struct Fact<0> {
	static const long result = 1;
};

template <int N> struct E {
	// e = S(1/n!) = 1/0! + 1/1! + 1/2! + ...
	static const long Den = Fact<N>::result;
	typedef Frak< 1, Den > term;
	typedef typename E<N-1>::result next_term;
	typedef typename Sum< term, next_term >::result result;
};

template <> struct E<0> {
	typedef Frak<1, 1> result;
};

int main() {
    cout << (1.0 * E<8>::result::Num /  E<8>::result::Den) << endl;
    return 0;
}

Looking nice, isn't it? You should have all what's needed to understand what's going on there. Even more, almost everything has been explained in previous articles, with the exception of EqBase. But that's left as an exersice for the reader because the writer is too lazy.

If you think any part of the code requires clarification ask in the comments. Next, a long overdue topic: lists using template metaprogramming. Guaranteed to blow your mind into little pieces!

Random WTFs

Random WTF 1

Note: Use dapper instead of edgy to use Ubuntu Dapper

Thank you captian obvious.

Random WTF 2

I've been working with a big-co supplied ACS server, but it's IE only. WTF!? Aren't ACS all XMLy so they can work everywhere? I hate you all.

Template metaprogramming IV: Nightmares to come

By now you should have noticed the warnings were not in vain: we are exploring a bizarre side of C++ here, a side many people prefer to, wisely, ignore. Luckily it probably is too late for you, there is no way back. Only a long spiraling way down into the arms of despair and cryptic compiler error messages... mwahahahaha. But now, let's see where we are.

In previous entries we learned how to return values, how to define recursive devices and how to provide a partial specialization. Let's see know how can we use partial specialization and complex return type definitions for some more fun template metaprogramming tricks. We had a fraction and a ScalarMultiplication operation for Frak:

template <int N, int D> struct Frak {
static const long Num = N;
static const long Den = D;
};

template <int N, class X> struct ScalarMultiplication {
static const long Num = N * X::Num;
static const long Den = N * X::Den;
};

Let's try to add an operation to simplify a Fraction. Simplify< Frak<2, 4> > should return 1/2. Mph... simplifying a fraction means dividing it by the MCD. A quick trip to Wikipedia reveals a nice recursive way to implement an MCD device:

template <int X, int Y>	struct MCD {
static const long result = MCD<Y, X % Y>::result;
};
template <int X> struct MCD<X, 0> {
static const long result = X;
};

I won't get into much detail as the link explains it a lot better than whatever I could try, but do take a look at the definition of MCD: that's a partial specialization. No magic there. Back to our simplifying device, we now have all the parts for it. Going back to it's definition we can see that simple(fraction) = fraction / mcd(fraction). Then:

template <class F> struct Simpl {
static const long mcd = MCD<F::Num, F::Den>::result;
static const long new_num = F::Num / mcd;
static const long new_den = F::Den / mcd;
typedef Frak< new_num, new_den > New_Frak;
typedef typename New_Frak::result result;
};

Quite a mouthful, but a lot simpler than what you think as there is a lot of unnecessary code there. Until new_num and new_den, no surprises. Typedeffing a Frak is not new, either. typedef typename is something new: typename tells the compiler you're referring to a name inside a template class, otherwise it'd try to refer to a static variable inside said class (*). Knowing what each thing does we can simplify it:

template <class F> struct Simpl {
static const long mcd = MCD<F::Num, F::Den>::result;
typedef typename Frak< F::Num / mcd, F::Den / mcd >::result New_Frak;
};

It is a matter of style really. In this case I'd rather use the second one because it matches better its colloquial definition, but if you think the first one is more readable go with it... it doesn't really matter though, no one will ever even try to read this kind of code if you intend to use it in a real application.

Next time: a "useful" (**) and complete template metaprogramming device, using the complete toolset we've been learning in this crazy templating series.

(*) Think of it this way:

struct Foo {
   typedef int Bar;
   Bar bar;
};

In a template you don't know if Bar is a typename or varname because there's no access to the specific template definition. As a rule of thumb, if the compiler complains then add typenames.

(**) Results may vary according to your definition of useful.

Ubuntu: Sound still FUBAR'd

Remember my problems with dual screen support in Ubuntu? Well, I still love bashing Ubuntu, and the sound system in Linux is certainly a topic to rant a lot. Making the sound work fine in Ubuntu is an odyssey in pain and frustration, unless it works fine out of the box. And even if it does, it may still have it's kirks. Lots of them.

In my case the sound starts in mute. I know it's a problem with pulse (which is a WTF in itself) and alsa, I don't really care what's the problem though, I just want to play my mp3s collection without having to carefully turn the knobs up to eleven in alsamixer.

After trying a lot of the "solutions" found on the internets I've decided the best thing to do, short of switching back to windows me, is adding the following to my "fix_ubuntu_fuckups.sh" start script, which already contains my dual-screen pseudofix:

amixer -c0 -- sset Master playback -0dB unmute
amixer -c0 -- sset Headphone playback 0dB unmute
amixer -c0 -- sset Front playback 0dB unmute
amixer -c0 -- sset PCM playback -16dB unmute

This sets alsamixer to normal volume levels. As for the real fix, I'll wait till the next Ubuntu version. I wonder which sound subsystem will they chose next time.

I'm a pirate!

Buguntu family album

This is a very cool family album: http://blog.nizarus.org/2010/04/ubuntu-the-family-album

Can't wait to upgrade to 10.04, my current install (9.10) is working like crap.

Template metaprogramming III: Entering Pandemonium

If you are here and you have read the previous two parts then you are crazy. If you haven't then go and read it, then never come back if you value your sanity at all. We saw last time an example of a factorial using template metaprogramming, now it's time for something a little bit more fun. I was thinking on lists, but that's a bit too much for starters: let's do some more math. Now with fractions!

So, how would you express a fraction? The fun part, and you already know this, you have only types (*), there are no variables. Luckly static const int saves the day:

template < int N, int D > struct Frak {
	static const long Num = N;
	static const long Den = D;
};

Woo hoo... how boring, let's do something on those Fraktions, so they don't get bored... like multiplying:

template < int N, typename X > struct ScalarMultiplication {
	static const long Num = N * X::Num;
	static const long Den = N * X::Den;
};

Well that does the job, I guess, but it's ugly. Too ugly... why would we redefine a Fraction when we already have a great definition? Let's try again:

template < int N, typename X > struct ScalarMultiplication {
	typedef Frak< N*X::Num, N*X::Den > result;
};

OK, now you think I'm pulling your leg, but, promise, I'm not. This actually works, and it looks nice! Check out that sexy typedef: you can't have variables, we said, so instead we return types. Frak is a type when binded to two concrete values, so Frak is a type too. Just typedef it to a result and be done with it.

How do we test if it worked? Easy:

int main() {
	typedef Frak< 2, 3 > Two_Thirds;
	typedef ScalarMultiplication< 2, Two_Thirds >::result Four_Sixths;
	std::cout << Four_Sixths::Num << "/" << Four_Sixths::Den << "n";
}

Nice! By now you should have learned how to return new types, which are the result types for template metaprogramming devices. You should have also learnt how to write a device which operates on another template device... congratulations, that's metaprogramming. Next time, something a little bit more interesting.

(*) Boring theory rant: What do I mean you can't have return values so you must use types instead? Let's see: a variable or an attribute are both parts of an object. If I have a variable named height in a class named Person, then each person gets his own height. Even if the numeric value is the same there won't be two shared height attributes. On the other hand static const vars are defining parts of classes, not objects; stupidity could be static const var of Person (only in this case we'd all be equally stupid... this is were the analogy falls apart, I'm sorry).

Knowing the difference between an object and a class defining characteristics, it is clear we can only use static const stuff - it's nonsense talking about template-objects, it's all about template classes.

Ubuntu: Dual screen still FUBAR'd

I'm quite sure I have written about this before but I'm too lazy to search for the article right now. Well, dual screens in Ubuntu still sucks. Much less than ever before, granted, but it still works quite bad. In my specific case the whole desktop is shown, in both monitors (which by itself is a huge improvement over previous versions) but the working area is clipped to the notebook's monitor size. Not nice.

To fix this problem (more like hacking it away, actually) I keep a handy bash script in the top left corner on my desktop:

xrandr --output HDMI-2 --right-of HDMI-1 --mode 1680x1050 --rotate normal

Also, as I have two nice rotable monitors at work it's nice that now Ubuntu supports actually rotating the picture displayed in the monitor (thanks Ubuntu for coming up to speed... with windows 98, that is). Obviously I keep another script for this, as it doesn't really work by default:

xrandr --output HDMI-1 --left-of HDMI-2 --mode 1680x1050 --rotate left
xrandr --output HDMI-2 --left-of HDMI-1 --mode 1680x1050 --rotate normal

Even though I love bashing Ubuntu (and bash) I'm quite confident most, if not all, of this issues will be gone in future versions of the OS.

Template metaprogramming II: Openning the box

We saw last time how to print a factorial using only template metaprogramming, but didn't explain anything about it. I promised to fix that in this article. Starting by the very beginning:

template <int N> struct Factorial {
	static const int result = N * Factorial<N-1>::result;
};

template <> struct Factorial<0> {
	static const int result = 1;
};

int main() {
	std::cout << Factorial<5>::result << "n";
	return 0;
}

Why static const?

Templates get evaluated on compile time, remember? That means all that code actually executes when compiling the source, not when executing the resulting binary (assuming it actually compiles, of course). Having as a constraint the fact that all your code must resolve on compile time means only const vars make sense. Also, as you're working with classes (templates are applied to classes, not objects) only static objects make sense.

That explains the static const thing, what about the Factorial<0>? Well it's obviously an edge case. It describes a specific case of a Factorial. It's a specialization! Why do we need it? Take a look again at the definition of struct Factorial: it's a recursive definition. How do we break from the recursive loop? With a base case, obviously.

If this is starting to remind you of anything then you are crazier than you think, and you already know some Haskel. Indeed, template metaprogramming has some resemblance to Haskel programming: no const "variables", no for-loop (only recursion), base cases (pattern matching), and cryptic error messages which makes you want to jump of a cliff.

A useful trick I learned when working with Haskel (many many years ago) is to declare the problem, instead of thinking it. For our problem the factorial of a number is defined as said number times the factorial of that same number minus one, being the factorial of 0 always 1.

Translating:

// the factorial of a number is defined as said number times
// the factorial of that same number minus one

template <int N> struct Factorial {
	static const int result = N * Factorial<N-1>::result;
};

// being the factorial of 0 always 1.
template <> struct Factorial<0> {
	static const int result = 1;
};

That's good for a first approach... next time something more complex (and less theory, promise).

---

Thanks to Stéphane Michaut for reporting broken code in this page.

Vim tip: Word count

Trying to count words is a common task. Whenever you're writting a report for class, that is. There are some legitimate reasons but they don't matter now: it's a great chance to show off how great Vim is.

First method: Type ggVgY"*p to copy the whole text. Then paste it into word and use word count.

Second method: Type %!wc -w, which executes wc on each line.
Third method: Type g^g (g, CTRL+g) and watch the bottom of your screen.

As ussual, Vim rocks.

Company policy

I liked this one:

Great for a 404.

Template metaprogramming: A slow descent towards utter maddness

There have been some articles dealing with template metaprogramming over here. Things like template <int n>, which look really weird (but behave in an even more bizarre way). This post starts a series of articles following the contrived and tortuous path down insanity lane and into the mouth of the beast. When we are done things like typedef typename should be clearer than i=i++, should you dare to keep on reading.

First things first: Why TF would I...

Instead of explaining why let's start backwards: assume you already want to start learning some template metaprogramming. Yeah, I'm sure there are many legitimate reasons, like job security or job security perhaps, but if you want to learn template metaprogramming the most likely explanation is you are nuts. Plain and simple.

Practical uses? Not really. Yeah, there are some (if you are a boost developer) and lets you write some neat stuff, but in your every day job you are most likely never going to use them. And that is a good thing (tm), for mere mortal programmers tend to like getting their jobs done. Having said that, let's learn some template metaprogramming!

Metawhat?

First, we need to start with a little clarification: using template to parametrize a class, something like std::vector does, is not template metaprogramming. That's just a generic class (Java-pun intended). That is indeed a useful case for templates, but it has little fun in it.

Template metaprogramming is much more fun than mere generic classes. The template processing in C++ is a language on it's own (no, really, like a Turing complete language and everything), though a language with very weird syntax and a very strange "design". Design between quotes because there was no design in its initial stages, template processing is a sub-language organically grown as a side effect of adding partial templates specialization (more on this later), so don't expect a nice language. Here, let me show you an example of another organically grown language: Microsoft's .bat scripting. You can imagine now what kind of beast this is if we are comparing it to bat scripts, right? (Nitpickers note. yup, I do know bat scripting is not a real language as it's not Turing complete. The comparison still stands though).

First step

Enough chatter. Let's start with an empty program and work our way down from there:

template <int N> struct Factorial {
 static const int result = N * Factorial::result;
};

template <> struct Factorial<0> {
 static const int result = 1;
};

int main() {
 std::cout << Factorial<5>::result << "n";
 retrun 0;
}

Whoa. Lots of magic going on there, on the simplest of all template metaprogramming tricks. But I don't feel like explaining it right now, I'm too sleepy, so I will leave that for next post.

Changing default file associations in gnome

It's been a long time since I posted a Linux related tip. Not in the mood I guess... well, this is one which really annoyed me, until I found out how easy it is: I hate some of the default file associations in gnome. Movieplayer, for example, is a horrible choice. Breaking and devolving with each new distro release, I have decided to settle with vlc as my default movie player, yet I couldn't easily change the default file type association. After fiddling around with the thingy in gnome resembling a regedit (ugh) I found out the easy way:

* Right click the file for which you want to change default associations and click properties
* Select "open with" tab
* ...
* Profit!

I hearth Berkeley

error: cannot convert ‘Db**’ to ‘DB**’ for argument ‘1’ to ‘int db_create(DB**, DB_ENV*, u_int32_t)’

Thank you very much, Oracle Berkeley, for having a type named Db and another one named DB, and for never using namespaces. It makes my work a much more interesting challenge (*).

(*) Yeah, I know, Db is for the C++ wrapper and DB is for the plain C API (**). So what, I hate you all anyway.

(**) I'm working on a project with Berekley DB and it has enough WTF moments for a complete blog... I may post some of them, as a catharsis method. (***)

(***) Or because it has some interesting stuff too... who knows. Recursive note FTW (**). I think I have already done that, haven't I?

Fixed string: POD String datatype

We saw in POD types in C++ the difference between a POD and a non-POD type but the question of how to apply this knowledge to persist an std::string-like object remained open. This problem is a specific version of how to persist an object from which you know the size but has internal buffers using the heap instead of using only stack memory.

The best example for this case is, perhaps, a column from a table. You know the upper limit of the string's length but using std::string is clearly much better (easier) than a char[N]. Yet you'd be loosing the ability to persist this object in a generic way (i.e. copying memory instead of knowing the object's internal structure).

Well, there's an easy solution (though more than a solution I'd call it an acceptable trade-off) in which you can create a char[N], a char buffer, with std::string-like behaviour and yet POD-safe (almost POD safe actually, as we'll see now).

What's a POD?

POD datatypes, though informally explained in "POD types in C++" have a formal definition which you can look in Google. For practical terms a POD is a trivial object: no custom constructors, no virtual functions, nada of the fun stuff C++ can give you (or a native type, obviously).

Although this definition gives us quite a hard constraint we can create a quasi POD object (!) that does not conform to the standard definition of POD, yet has all the properties of one. This is the kind of struct we'll be creating. It would crash our program if used in a printf, but resides completly on the stack.

Implementing a POD string

A word of warning: ignore for now the "template " part; that's a template metaprogramming technique which we'll discuss some other day.

template  <int N> struct FixedString {
   mutable char str[N];
   FixedString() { str[0] = 'X'; }
   FixedString(const char* rid){ memcpy(str, rid, sizeof(str)); }
   FixedString(const FixedString &rid){ memcpy(str, rid.str, sizeof(str)); }
   operator const char*() const { return str; }
};

You can see now why I called it a trade-off: it works as we intend it to work but it does have its rough edges (most notably the const char/mutable part). It'll allow you to use a char[N] with some behaviour of an std::string; use it with caution.

POD types in C++

Let's say you have something like this:

typedef int A;
void x(A);

struct B {
   int b;
   B(int b) : b(b) {}
   virtual void x() = 0;
};

Regardless of what does function x do, what's the difference between A and B? Without getting too picky and leaving semantics aside, we may say there is no difference in behaviour. There's however a small gotcha there, which is completely irrelevant for C++ code but can bite you in the ass when interfacing C and C++. Would this work?

{
   A a; B b;

   // Case 1
   A *p = malloc(sizeof(A));
   memcpy(p, &a, sizeof(A));

   // Case 2
   B *p = malloc(sizeof(B));
   memcpy(p, &b, sizeof(B));
}

The answer is perhaps. In most cases it would work, in some cases it won't. C++ uses a vtable to dispatch virtual methods, so if I were to perform a memcpy of an object, then store it on disk and retrieve it afterwards I don't have any guarantees the vtable will still be valid. And that's leaving aside the case of objects having dynamically allocated memory themselves.

Wrapping up, the difference between A and B is simple: A is a POD (Plain Old Datatype, POJO for you Java guys) type, B is not. There are some other things non-POD objects can't do, for example this is invalid:

   B b;
   printf("%i", b);

Not only it's invalid: g++ emits a warning and then crashes on runtime (this is related to the use of vargs in functions with "..." params, but it's not important now).

Knowing what a POD object is, what would you do now if you had to persist (serialize) an std::string-like object? That's a topic for the next post.

Operator sizeof (AKA Reading Berkeley's FM, take II)

Last time I told you about an evil snipet I found on Oracle Berkeley DB's manual:

  skey->size = sizeof((struct student_record *)pdata->data)->last_name;

And we concluded it's trying to... well, dereference a number. And yet it compiles. What the hell is going on there?

The answer here is in the subtleties of the sizeof operator. That's right, operator, not function. Plus is an operator. Less is an operator. * is a (unary) operator. sizeof is a unary operator too. The relevance of this is that operators can behave in more bizzare ways than functions do. In this case there's a difference between this two lines:

  MyClass x;
  int a = sizeof(MyClass);
  int b = sizeof(x);

A very subtle difference. Can you spot it? a and b will have the exact same value, rest assured. The difference is in the operator itself: sizeof MUST have parenthesis when applied to a type name, yet parenthesis are optional when applied to an instance of a datatype, so this code is legal:

  MyClass x;
  int a = sizeof(MyClass);
  int b = sizeof x;

Oh, wait, the fun doesn't stop there: sizeof also has bizarre precedence order, meaning it won't get applied as you expect it. So, this is valid too:

  struct MyClass { int y; } x;
  int b = sizeof x->y;

Can you see where we are going? Knowing that sizeof will be applied last lets you write something like this too:

  void *ptr = ...
  int b = sizeof((X*)ptr)->y;

Which means nothing else than "store in b the size of member y in struct X. It should be easy to see why BDB's example does compile, and why did I spend half an hour trying to understand the reason it compiled fine.

By using some more casts and a clever arangement of parenthesis you can come up with a great job security device.

Reading Berkeley's FM

I got this from Oracle Berkely DB's FM:

  skey->size = sizeof((struct student_record *)pdata->data)->last_name;

Take a good look at that pice of code:

  a_number = sizeof((T*)pdata->data)->last_name;

Again:

  a_number = sizeof(Whatever)->field;

Wait a minute. typeof(sizeof(x)) == const unsigned int. Right? So, again:

  a_number = 42->field;

There's no way that first line can compile. Go and check it (in the example, not the last line please). I'll wait. Done? Yeap, I was surprised to, it does indeed compile. Mi first reaction towards this discovery went something like this:

What is going on there? It took me a while to figure out how evil Berkely 's manual can be. The answer next time.

I hate Berkeley

Polymorphism taken to 11:

SQL Term	Oracle Berkeley DB Equivalent
Database	Environment
Table	Database
Tuple/row	Key/data pair
Secondary index	Secondary database

WTF ORACLE, WTF.

You know you're a geek...

... when you try to log in to your homebanking account using admin:admin (*) (**)

---

(*) Alt take: a geek with weak passwords, yeah. My pin is 1234 and I'll never change it.

(**) Replace homebanking with gmail, linkedin and $LATEST_NETWORKING_FAD and you're most likely mental. (***)

(***) Replace mental with (*) to obtain a Moebious post.

/Delirious posting mode, deactivate!

Cofeeeeeee

int main() {
	otl_connect db;
	otl_connect::otl_initialize();
	db.rlogon("whatever");

	int cuarentaydos;
	const char *sql = "select 42 drom dual";
	otl_stream stmt(1, sql, db);

	if (!stmt.eof()) stmt >> cuarentaydos;
	std::cout << "En la base 42 == " << cuarentaydos << "n";
	db.logoff();
}

I spent half an hour looking for the error. How come drom is not a standard sql keyword? Damn!

C++: Composite objects and throwing constructors

Check out the following code:

struct Foo {
        struct Foobar{ Foobar(){ throw "foobar'd"; } };
        Foobar baz;

        Foo() try : baz() {
                cout << "Ctr 1n";
        }catch(...){
                cout << "Ctr 2n";
        }
};

int main() {
        Foo bar;
        cout << "End!n";
        return 0;
}

Nice, isn't it? Without using a compiler answer the following questions:

• Does it compile?
• If it does, does it abort or does it return 0?
• What does it print?

Did you think about it? Come on, I'll wait... ready? OK, lets go.

First we should think about something else: what the fuck is that thing? I would surely be horrified if I found something like that was lurking in one of my projects' code. It's hideous. And it's called a "Constructor function-try-block" (yes, answering the first question, it does compile and it indeed is valid C++ code).

A constructor function-try-block exists only to catch exceptions thrown while constructing a composite object. This may tempt us to answer the second question: it should return 0, as we're catching Foobar's exception on Foo's ctr. But that's not how these things work , otherwise this would have been a very boring entry: the program aborts.

To understand why does this program abort you should think what does it mean to have a composite object; there is no meaning in having a Foo without a Foobar. baz, of type Foobar is a part of Foo, just like a head is a part of a person and there's no person without a head (though many act as if they didn't have a working head, but that is a topic for another day).

Now, what does it mean to throw (regardless wheter this is a good or a bad practice) in a constructor? It is like saying "There's been a horrible error and I have no idea how to recover. Man, I give up". Throwing in a ctr means there's no point in trying to fully construct that object: it leaves a half-built thing. What can you do with that half object? Nothing, throw it away.

Now that we know what does it mean to throw in a constructor we can answer why does the program abort: there is no point in building a composite object when one of its constituting parts can NOT be constructed, thus it must throw as well.

The last point, why do we have function try blocks if we can't catch exceptions? Well... you can't catch it but you may rethrow a different one, or use the constructor to clean up the mess you would otherwise leave behind. Or you could write a snippet of code, post it on your blog and confuse a whole lot of people (all 3 of them reading this block. Hi grandma).

Oh, we had a third question, but you should be able to answer that one yourself.

PS: You may get a better explanation at GotW #66: Constructor Failures

Valgrind – OCI: Suppressions file, Take II

Remember my OCI suppressions file? Well, since then I have updated it. Now it includes some more suppressions, for libnetsnmp, Oracle, Berkeley DB, and may be something else I can't remember.

If you add anything else let me know in the comments.

BTW last time attaching this file failed so now I'm posting it in the first comment after this entry.

Back for round II

OK, the hiatus is over. It's not like I've been sitting around doing nothing this last couple of months... well may be I have, but now I'm back. Kind off, I'm actually going out on vacations a couple of weeks in march but the blog will be on autopilot  and there are quite a lot of posts in the backlog... there are a couple of months more worth of clever and informative (?) articles, so stay tuned (?^2).
